Redodo 12.8V 200Ah Low Temp Cutoff LiFePO4 Battery and 12V 20A Charger User Manual

1. ບົດແນະນຳ

Thank you for choosing the Redodo 12.8V 200Ah Low Temperature Cutoff LiFePO4 Battery and 12V 20A Charger. This manual provides essential information for the safe and efficient operation, installation, and maintenance of your battery system. Please read this manual thoroughly before use and retain it for future reference.

This LiFePO4 battery is designed for deep cycle applications, offering high energy density, stable performance, and a long cycle life. It features a built-in Battery Management System (BMS) with low temperature cutoff protection, making it suitable for various applications including RVs, solar energy systems, off-grid setups, and trolling motors.

2. ຂໍ້ມູນຄວາມປອດໄພ

ຄຳເຕືອນ: ການບໍ່ປະຕິບັດຕາມຄໍາແນະນໍາດ້ານຄວາມປອດໄພເຫຼົ່ານີ້ອາດຈະເຮັດໃຫ້ເກີດໄຟຟ້າຊັອດ, ໄຟໄໝ້, ການບາດເຈັບສາຫັດ, ຫຼື ການເສຍຊີວິດໄດ້.

• Always wear appropriate personal protective equipment (PPE) including safety glasses and insulated gloves when handling batteries.
• ຫ້າມບໍ່ໃຫ້ເກີດການວົງຈອນຂອງແບັດເຕີລີ່.
• ຢ່າໃຫ້ແບັດເຕີຣີຖືກໄຟ, ຄວາມຮ້ອນເກີນໄປ ຫຼື ແສງແດດໂດຍກົງ.
• ຫ້າມ​ເອົາ​ໝໍ້​ໄຟ​ໃສ່​ໃນ​ນ້ຳ ຫຼື​ຂອງ​ແຫຼວ​ອື່ນໆ.
• ຫ້າມຖອດປະກອບ, ຂັດ, ເຈາະ, ຫຼືດັດແປງແບັດເຕີຣີ.
• ຮັກສາແບັດເຕີຣີໃຫ້ຫ່າງຈາກເດັກນ້ອຍ ແລະສັດລ້ຽງ.
• Use only the specified Redodo 12V 20A charger or a compatible LiFePO4 charger.
• ຮັບປະກັນການລະບາຍອາກາດທີ່ເໝາະສົມໃນລະຫວ່າງການສາກໄຟ ແລະ ການຄາຍປະຈຸ.
• In case of fire, use a Class D fire extinguisher. Water can be ineffective and may worsen the situation.
• Do not use the battery as a starting battery for vehicles or in golf carts unless specifically designed for that purpose. This model is suitable for trolling motors with 30-70lbs thrust.

3. ສິ່ງທີ່ຢູ່ໃນກ່ອງ

ເມື່ອເປີດກ່ອງ, ໃຫ້ກວດສອບວ່າທຸກລາຍການມີຢູ່ແລ້ວ ແລະ ບໍ່ເສຍຫາຍ:

• 1 x Redodo 12.8V 200Ah Low-Temp LiFePO4 Battery
• 1 x Redodo 12V 20A LiFePO4 Battery Charger (if purchased as a kit)
• 2 x M8 Terminal Bolts
• 2 x Insulating Caps
• 1 x ຄູ່ມືຜະລິດຕະພັນ
• 1 x ບັດແນະນຳ

Image: The Redodo 12.8V 200Ah LiFePO4 battery, showcasing its overall design and branding.

ຮູບພາບ: ລາຍລະອຽດ view of the battery's M8 terminal specifications, including dimensions for the 9/16 inch bolt length and 5/16 inch diameter.

4. ຄຸນລັກສະນະຂອງຜະລິດຕະພັນ

• Low Temperature Cut-Off Protection: The integrated BMS prevents charging below 0°C (32°F) and resumes at 5°C (41°F). Discharging is cut off below -20°C (-4°F).
• ເຊວຊັ້ນລົດຍົນ: Constructed with prismatic LiFePO4 cells for higher energy density, stable performance, excellent high-temperature performance, low self-discharge, and high power output.
• ຄວາມໄວໃນການສາກໄວ: The accompanying 14.6V 20A charger can charge a 12V 100Ah LiFePO4 battery to 50% in 2.5 hours, twice as fast as a standard 10A charger.
• Space Efficient Charger Design: The 14.6V 20A charger features fixing hole positions for easy installation and an AC end control switch for convenient operation.
• Exceptional Longevity: Offers 4000-15000 cycles, providing a service life of up to 10 years, making it a durable alternative to lead-acid batteries.
• Expandable Energy: Provides a maximum load power of 1280W and 2560Wh energy. Supports up to 4P4S configuration for a 51.2V 800Ah battery bank, yielding up to 40.96kWh energy and 20.48kW continuous load power.
• Trolling Motor Compatibility: Suitable for trolling motors with 30-70lbs thrust.

Image: Illustration of the battery's low temperature cut-off feature, showing charging cut-off at 0°C/32°F and discharging cut-off at -20°C/-4°F, ensuring battery safety in cold conditions.

Image: Diagram illustrating the six intelligent BMS protections: Low Temp Cut Off, Over-charge, Over-discharge, High Temp Cut Off, Short Circuit, and Over-current protection.

Image: Visual representation of the battery's Grade A cells, highlighting anti-moisture, anti-dust, and anti-salt fog properties, suitable for trolling motors (30-70lbs).

5. ຕັ້ງຄ່າ

5.1 ການກວດກາເບື້ອງຕົ້ນ

Before installation, inspect the battery for any visible damage. Ensure terminals are clean and free of corrosion. Confirm all components listed in "What's in the Box" are present.

5.2 Battery Placement

Place the battery in a clean, dry, and well-ventilated area. Ensure it is secured to prevent movement or damage during operation, especially in mobile applications like RVs or boats. Avoid locations with extreme temperatures or direct exposure to water.

5.3 ການເຊື່ອມຕໍ່ຫມໍ້ໄຟ

1. Ensure all loads are disconnected and the charger is off before making any connections.
2. Connect the positive (+) terminal of the battery to the positive (+) terminal of your system (e.g., inverter, charge controller).
3. Connect the negative (-) terminal of the battery to the negative (-) terminal of your system.
4. Use the provided M8 terminal bolts and insulating caps to ensure secure and safe connections.
5. For multiple batteries in series or parallel, refer to the "System Expansion" section for specific wiring diagrams and precautions. This battery supports up to 4P4S configuration.

Image: Diagram illustrating a typical solar power system setup with the Redodo LiFePO4 battery bank, solar panels, MPPT controller, and inverter, demonstrating how to connect for home energy storage.

5.4 ການສາກໄຟເບື້ອງຕົ້ນ

It is recommended to fully charge the battery before its first use. Connect the Redodo 12V 20A charger to the battery terminals, ensuring correct polarity. Plug the charger into an AC power source. The charger's indicator lights will show the charging status. Allow the battery to charge until the charger indicates a full charge.

ຮູບພາບ: ໃກ້ຊິດ view of the Redodo 14.6V 20A LiFePO4 battery charger, highlighting its pluggable connection and indicator light colors for charging status.

Image: The Redodo 14.6V 20A battery charger, emphasizing its aluminum casing and built-in cooling fan for excellent heat dissipation.

Image: Visual detailing the comprehensive safety protections of the Redodo charger, including output short-circuit, temperature, output over-voltage, and reverse polarity connection protection.

6. ຄໍາແນະນໍາການດໍາເນີນງານ

6.1 ການນໍາໃຊ້ທົ່ວໄປ

Once installed and fully charged, the battery is ready for use. Connect your desired loads to the battery system. The integrated BMS will manage the battery's performance, protecting against over-charge, over-discharge, over-current, short circuits, and temperature extremes.

6.2 ການສາກໄຟ

• Always use a LiFePO4 compatible charger.
• ຮັບປະກັນການສາກໄຟ voltage is within the specified range (typically 14.4V - 14.6V).
• The BMS will automatically stop charging if the battery temperature drops below 0°C (32°F) and resume when it rises above 5°C (41°F).
• Multiple charging methods are supported, including dedicated LiFePO4 chargers, solar panels with MPPT controllers, and generators with DC-DC chargers.

Image: Illustration showing various charging methods for the Redodo LiFePO4 battery, including a dedicated charger, solar panel with MPPT, and a generator with a DC-DC charger.

6.3 ການປົດປ່ອຍ

• The battery is designed for deep cycle applications.
• The BMS will automatically cut off discharge if the battery temperature drops below -20°C ( -4°F) to protect the cells.
• Avoid exceeding the maximum continuous discharge current specified in the product specifications.

7. ບໍາລຸງຮັກສາ

7.1 ການທໍາຄວາມສະອາດ

ຮັກສາຂົ້ວແບັດເຕີຣີ ແລະ c ໄວ້asing clean. Use a dry cloth to wipe away dust and dirt. If necessary, use a slightly damp cloth, ensuring no moisture enters the battery or charger. Do not use solvents or harsh chemicals.

7.2 ການເກັບຮັກສາ

• For long-term storage, charge the battery to approximately 50-70% State of Charge (SoC).
• ເກັບຮັກສາຫມໍ້ໄຟໃນບ່ອນທີ່ເຢັນ, ແຫ້ງ, ຫ່າງຈາກແສງແດດໂດຍກົງແລະອຸນຫະພູມທີ່ສຸດ.
• Disconnect all loads and the charger when storing the battery.
• ກວດສອບລະດັບຄວາມດັນຂອງແບັດເຕີຣີເປັນໄລຍະtage during long-term storage and recharge if necessary to prevent deep discharge.

7.3 ການກວດສອບປົກກະຕິ

• Regularly inspect the battery and connections for any signs of damage, loose connections, or corrosion.
• Ensure proper ventilation around the battery, especially during charging and heavy use.

8. ການແກ້ໄຂບັນຫາ

9. ຂໍ້ມູນຈໍາເພາະ

Image: The Redodo 12.8V 200Ah LiFePO4 battery with its dimensions clearly labeled: Height 8.58 in (218 mm), Width 9.45 in (245 mm), Length 20.55 in (522 mm).

10. ການຮັບປະກັນແລະການສະຫນັບສະຫນູນ

Redodo LiFePO4 batteries are designed for exceptional longevity, with a typical lifespan of up to 10 years and 4000+ cycles. This product comes with a 5-year guarantee.

For technical support, warranty claims, or any questions regarding your Redodo product, please contact Redodo customer service. Please have your model number (R12V200-100-LOW-TEMP-8-A160) and purchase date available when contacting support.

You can find more information and contact details on the official Redodo webເວັບໄຊທ໌ຫຼືຜ່ານເວທີການຊື້ຂອງທ່ານ.
