Invengo 3.2L Stainless Steel Pet Water Fountain (Model: SSPF-HT01)

1. ບົດແນະນຳ

This manual provides detailed instructions for the Invengo 3.2L Stainless Steel Pet Water Fountain (Model: SSPF-HT01). This automatic pet water dispenser is designed to provide fresh, filtered water for cats and dogs, promoting healthy hydration. Constructed from food-grade 304 stainless steel, it offers a hygienic and durable alternative to plastic fountains. Key features include a large capacity, an ultra-quiet pump, and a multi-layer filtration system.

2. ເນື້ອໃນຊຸດ

ກວດ​ສອບ​ວ່າ​ລາຍ​ການ​ທັງ​ຫມົດ​ທີ່​ລະ​ບຸ​ໄວ້​ຂ້າງ​ລຸ່ມ​ນີ້​ແມ່ນ​ລວມ​ຢູ່​ໃນ​ຊຸດ​ຂອງ​ທ່ານ​:

• Stainless Steel Fountain Unit (3.2L/108oz capacity)
• ປ້ຳນ້ຳ
• AC to USB-A Power Adapter
• Power Cable with Barrel Connector
• 4 x Replacement Carbon Filters (1 pre-installed, 3 extra)
• 4 x Replacement Foam Sponges (1 pre-installed, 3 extra)
• Spout Options (Curved stainless steel spout, Dolphin spout, Gentle bubbling fountain attachment)
• ແປງເຮັດຄວາມສະອາດ 2 ອັນ
• ຄູ່ມືຜູ້ໃຊ້

3. ຂໍ້ມູນຈໍາເພາະ

4. ຄໍາແນະນໍາການຕິດຕັ້ງ

1. ຖອດ​ອອກ​ແລະ​ທໍາ​ຄວາມ​ສະ​ອາດ​: Carefully remove all components from the packaging. Wash the stainless steel bowl, lid, water pump, and all spout attachments with mild soap and water. Rinse thoroughly to remove any residue.
2. ປະກອບ Pump: Disassemble the water pump by gently pulling its parts apart. Clean the impeller (the small rotating part) and the internal sponge filter. Reassemble the pump securely.
3. ຕິດຕັ້ງຕົວກອງ:
   • Soak a new carbon filter in a separate bowl of water for 5 minutes before its first use. This helps remove any loose carbon dust and ensures proper water flow.
   • Place one foam sponge around the water pump.
   • Insert the soaked carbon filter into the designated filter housing located on the underside of the lid. Ensure it fits snugly.
4. Choose Spout Option: Select your preferred water flow style. The fountain includes a curved stainless steel spout for a flowing stream, a dolphin-shaped attachment for a playful stream, and a gentle bubbling fountain attachment. Attach your chosen spout to the water pump's outlet on the lid.
5. ຕື່ມນ້ໍາ: Place the lid assembly (with pump and filters attached) onto the stainless steel bowl. Fill the bowl with fresh water up to the "MAX" line, which is visible through the transparent LED water level window. Do not overfill.
6. ເຊື່ອມຕໍ່ພະລັງງານ: Route the power cable through the designated cable clip on the side of the lid to ensure a secure fit and prevent kinks. Connect the barrel connector end of the power cable to the water pump and the USB-A end to the provided power adapter. Plug the power adapter into a standard wall outlet.

5. ຄໍາແນະນໍາການດໍາເນີນງານ

• ເປີດ: Once the fountain is properly assembled and plugged into a power outlet, the water pump will automatically begin circulating water, and the LED light will illuminate.
• ການຕິດຕາມລະດັບນໍ້າ: The transparent LED water level window allows for easy monitoring of the water volume. Ensure the water level remains above the "MIN" mark to prevent the pump from running dry, which can cause damage. Refill as needed.
• Encouraging Drinking: The dual water flow designs (flower spout or gentle bubbling) are intended to attract pets and encourage them to drink more frequently. Observe your pet's preference and adjust the spout accordingly.

6. ບໍາລຸງຮັກສາ

Regular maintenance is crucial for the longevity and hygienic operation of your pet water fountain.

• ທໍາຄວາມສະອາດປະຈໍາອາທິດ: Disassemble the entire fountain unit. Wash the stainless steel bowl, lid, and all attachments with mild soap and water. Use the provided small cleaning brushes to thoroughly clean the pump's intake and spout areas, removing any hair or debris. Rinse all parts completely before reassembly.
• Monthly Pump Cleaning: At least once a month, fully disassemble the water pump. Clean the impeller and its housing to prevent mineral buildup and ensure quiet, efficient operation.
• ການທົດແທນການກັ່ນຕອງ:
  • Replace the carbon filter every 2 to 4 weeks. The frequency may vary depending on the number of pets using the fountain and the hardness of your water.
  • Replace the foam sponge filter every 1 to 2 months.
  • Always soak new carbon filters in water for 5 minutes before installation.

7. ການແກ້ໄຂບັນຫາ

• Fountain Not Running:
  • ໃຫ້ແນ່ໃຈວ່າອະແດບເຕີໄຟຟ້າໄດ້ຖືກສຽບເຂົ້າກັບປລັກສຽບຝາທີ່ໃຊ້ງານໄດ້ຢ່າງປອດໄພແລ້ວ.
  • Check that the power cable is properly connected to the pump.
  • Verify that the water level is above the "MIN" mark.
  • Disassemble and clean the pump, checking for any blockages or debris.
• ການດໍາເນີນງານທີ່ມີສຽງດັງ:
  • Ensure the water level is sufficient; low water can cause pump noise.
  • Clean the pump and impeller thoroughly to remove any debris or mineral buildup.
  • Check that all components are correctly assembled and seated properly.
• ນ້ຳບໍ່ໄຫຼ:
  • Inspect the pump for any blockages or foreign objects.
  • Ensure the carbon filter and foam sponge are not clogged. Replace if necessary.
  • Verify that the spout is correctly attached and not obstructed.

8. ການຮັບປະກັນແລະການສະ ໜັບ ສະ ໜູນ

For warranty information, please refer to the product packaging or the official Invengo website. If you encounter any issues not covered in this manual or require further assistance, please contact Invengo customer support.

ຂໍ້ມູນຕິດຕໍ່: Please refer to the contact details provided on your product packaging or the manufacturer's official webເວັບໄຊ.
