Eureka Forbes SmartClean Auto Bin S2 Robotic Vacuum Cleaner User Manual

1. ບົດແນະນຳ

This manual provides essential instructions for the safe and efficient operation, maintenance, and troubleshooting of your Eureka Forbes SmartClean Auto Bin S2 Robotic Vacuum Cleaner. Please read this manual thoroughly before using the product and retain it for future reference.

2. ຂໍ້ມູນຄວາມປອດໄພ

ເພື່ອຫຼຸດຜ່ອນຄວາມສ່ຽງຕໍ່ການບາດເຈັບຫຼືຄວາມເສຍຫາຍ, ໃຫ້ສັງເກດເບິ່ງຄວາມລະມັດລະວັງດ້ານຄວາມປອດໄພຕໍ່ໄປນີ້:

• ໃຫ້ແນ່ໃຈວ່າອະແດັບເຕີໄຟຟ້າເຂົ້າກັນໄດ້ກັບການສະຫນອງພະລັງງານໃນທ້ອງຖິ່ນຂອງທ່ານ.
• ຢ່າໃຊ້ຫຸ່ນຍົນໃນສະພາບແວດລ້ອມທີ່ປຽກ ຫຼື ໃກ້ກັບຂອງແຫຼວ.
• ຮັກສາຜົມ, ເຄື່ອງນຸ່ງວ່າງ, ນິ້ວມື, ແລະທຸກພາກສ່ວນຂອງຮ່າງກາຍໃຫ້ຫ່າງຈາກຊ່ອງເປີດ ແລະພາກສ່ວນທີ່ເຄື່ອນຍ້າຍ.
• ຢ່າອະນຸຍາດໃຫ້ເດັກນ້ອຍໃຊ້ຫຸ່ນຍົນ. ໃຫ້ເບິ່ງແຍງເດັກນ້ອຍ ແລະ ສັດລ້ຽງເມື່ອຫຸ່ນຍົນກຳລັງເຮັດວຽກ.
• Remove any loose cables, small objects, or fragile items from the cleaning path before operation.
• Use only the manufacturer-specified charging adapter and accessories.
• ຫ້າມ​ໃຊ້​ຫຸ່ນ​ຍົນ​ເພື່ອ​ເກັບ​ເອົາ​ສິ່ງ​ເສດ​ເຫຼືອ​ຂະ​ຫນາດ​ໃຫຍ່, ຂອງ​ມີ​ແຫຼມ, ຫຼື​ອຸ​ປະ​ກອນ​ການ​ເຜົາ​ໄຫມ້ / ສູບ​ຢາ.

3. ເນື້ອໃນຊຸດ

ກວດ​ສອບ​ວ່າ​ລາຍ​ການ​ທັງ​ຫມົດ​ແມ່ນ​ມີ​ຢູ່​ໃນ​ຊຸດ​:

• Eureka Forbes SmartClean Auto Bin S2 Robotic Vacuum Cleaner
• Self-Emptying Dust Bin (Auto Bin S2)
• ອະແດບເຕີການສາກໄຟ
• ຄູ່ມືຜູ້ໃຊ້

This image displays the Eureka Forbes SmartClean Auto Bin S2 robotic vacuum cleaner alongside its self-emptying dust bin. The robotic unit is circular and black, designed for floor cleaning, while the taller, rectangular black unit serves as the automatic dust collection station.

4. ຜະລິດຕະພັນເກີນview

The Eureka Forbes SmartClean Auto Bin S2 is an advanced robotic vacuum cleaner designed for comprehensive home cleaning. Key features include:

• ແຮງດູດສູງ 9000Pa: Delivers powerful cleaning for various debris.
• LiDAR 3.0 Smart Navigation: For accurate home mapping and efficient cleaning paths.
• Wet Mopping Function: Provides simultaneous vacuuming and mopping.
• Self-Emptying Dust Bin: Offers up to 65 days of hands-free dust disposal.
• ເວລາແລ່ນ 5 ຊົ່ວໂມງ: Extended cleaning sessions with a 5,000mAh battery.
• ແອັບອັດສະລິຍະ ແລະ ການຄວບຄຸມສຽງ: Manage cleaning via the Smart Life app, Alexa, or Google Assistant.
• HEPA H13 Grade Filtration: Captures dust and allergens for cleaner air.

ທາງຕັດພາຍໃນ view of the robotic vacuum cleaner highlights its powerful suction mechanism, illustrating the 9000Pa suction capability designed to effectively remove dust and debris from floors.

The robotic vacuum cleaner is depicted on a tiled floor, demonstrating its wet mopping function. The image shows a clean, wet path behind the robot, indicating its ability to mop and clean surfaces.

5. ຕັ້ງຄ່າ

5.1 ການຫຸ້ມຫໍ່ແລະການຈັດວາງ

1. ເອົາສ່ວນປະກອບທັງຫມົດອອກຈາກການຫຸ້ມຫໍ່ຢ່າງລະມັດລະວັງ.
2. Place the self-emptying dust bin against a wall in an open area, ensuring there are no obstacles within 1 meter to the sides and 1.5 meters in front.
3. Connect the charging adapter to the dust bin and plug it into a power outlet.

5.2 ການສາກໄຟເບື້ອງຕົ້ນ

Place the robotic vacuum cleaner onto the charging contacts of the self-emptying dust bin. Ensure the robot is properly docked. The indicator lights will show charging status. Fully charge the robot before first use (approximately 5 hours).

5.3 ການເຊື່ອມຕໍ່ ແລະ ການສ້າງແຜນທີ່ແອັບ

1. Download the 'Smart Life' app from your smartphone's app store.
2. ລົງທະບຽນຫລືເຂົ້າບັນຊີຂອງທ່ານ.
3. Follow the in-app instructions to add your SmartClean Auto Bin S2.
4. Initiate the quick home mapping process through the app. The LiDAR 3.0 system will map your home in approximately 5 minutes.

The robotic vacuum cleaner is shown actively mapping a room using its LiDAR 3.0 technology. A smartphone screen in the foreground displays the generated floor plan, indicating the device's ability to quickly and accurately map the home environment.

6. ຄໍາແນະນໍາການດໍາເນີນງານ

6.1 ການເລີ່ມຕົ້ນ/ຢຸດການທໍາຄວາມສະອາດ

• Press the power button on the robot or use the 'Smart Life' app to start or pause a cleaning cycle.
• The robot will automatically return to its charging dock when cleaning is complete or battery is low.

6.2 ຮູບແບບການທໍາຄວາມສະອາດ

Select various cleaning modes via the 'Smart Life' app:

• ເຮັດຄວາມສະອາດອັດຕະໂນມັດ: Standard cleaning for the entire mapped area.
• ສະອາດຈຸດ: Cleans a specific area intensively.
• ເຂດສະອາດ: ອະນາໄມເຂດທີ່ຜູ້ໃຊ້ກຳນົດໄວ້ໃນແຜນທີ່.
• ຜ້າປຽກ: Activates the mopping function. Ensure the water tank is filled and mopping pad is attached.

This composite image illustrates the robotic vacuum cleaner's versatility across different floor surfaces, including carpet, tile, marble, and wood, showcasing its 2-in-1 dry vacuuming and wet mopping technology.

6.3 ການກຳນົດເວລາ ແລະ ການປັບແຕ່ງ

Use the 'Smart Life' app to:

• ກຳນົດຕາຕະລາງເວລາທຳຄວາມສະອາດສຳລັບເວລາ ແລະ ມື້ສະເພາະ.
• Define 'No-Go Zones' or 'Virtual Walls' to restrict access to certain areas.
• Adjust suction power and water flow levels for mopping.

6.4 ການຄວບຄຸມສຽງ

Integrate your robot with Amazon Alexa or Google Assistant for hands-free control. Follow the instructions in the 'Smart Life' app to link your device.

This image highlights the robotic vacuum cleaner's smart navigation features, including anti-collision sensors that detect obstacles and anti-fall technology to prevent the unit from falling down stairs or ledges.

7. ບໍາລຸງຮັກສາ

7.1 Self-Emptying Dust Bin

The Auto Bin S2 automatically empties the robot's dustbin into a larger 4L dust bag, providing up to 65 days of hands-free cleaning. Replace the dust bag when the indicator light or app notification signals it is full.

A visual representation of the automatic dust collection system, showing the robotic vacuum cleaner docking with its self-emptying bin. The diagram illustrates how collected dust is transferred from the robot into the larger dust bag within the station, providing up to 65 days of hands-free operation.

7.2 ການບໍາລຸງຮັກສາການກັ່ນຕອງ

The robot is equipped with a HEPA H13 grade filter. Regularly clean the filter by tapping out debris. Replace the filter every 3-6 months, or as needed, to maintain optimal suction performance and air quality.

7.3 ຜ້າຖູພື້ນ ແລະ ຖັງນໍ້າ

• After each mopping session, remove and clean the mopping pad. Allow it to air dry completely before reattaching.
• Empty any remaining water from the water tank and rinse it. Do not leave water in the tank for extended periods.

7.4 ການເຮັດຄວາມສະອາດເຊັນເຊີ

Periodically wipe the robot's sensors (LiDAR, anti-collision, anti-fall) with a clean, dry cloth to ensure accurate navigation and obstacle detection.

8. ການແກ້ໄຂບັນຫາ

If you encounter issues with your SmartClean Auto Bin S2, refer to the following common solutions:

• ຫຸ່ນຍົນບໍ່ສາກໄຟ: Ensure the charging contacts on both the robot and the dock are clean and free of debris. Verify the power adapter is securely plugged in.
• ຫຸ່ນຍົນຕິດຢູ່ເລື້ອຍໆ: Remove obstacles from the cleaning path. Use the app to define 'No-Go Zones' for problematic areas. Clean the anti-collision sensors.
• ການດູດຊຶມບໍ່ດີ: Check if the dustbin is full or the dust bag needs replacement. Clean or replace the HEPA filter. Ensure the main brush is free of tangled hair or debris.
• mopping ບໍ່​ໄດ້​ຜົນ​: Ensure the water tank is filled and the mopping pad is clean and properly attached. Adjust water flow settings in the app.
• ບັນຫາການເຊື່ອມຕໍ່ແອັບ: Ensure your Wi-Fi network is stable and the robot is within range. Restart the robot and your router, then attempt to reconnect via the app.

9. ຂໍ້ມູນຈໍາເພາະ

The robotic vacuum cleaner is shown positioned under a sofa, with measurements indicating its compact design (9.6 cm height) allowing it to clean in low-clearance areas.

10. ການຮັບປະກັນແລະການສະຫນັບສະຫນູນ

Eureka Forbes is committed to providing excellent customer support:

• Free Post-Purchase Virtual Demo: Get acquainted with all features through a complimentary virtual demonstration.
• ໂທຟຣີ: Access 12-hour toll-free support.
• Video Call Assistance: Receive video call assistance within 24 hours.
• Doorstep Pickup & Drop: Available for repair needs.
• Extensive Service Network: Supported by India's largest and widest service network.

For detailed warranty information and to schedule support, please refer to the warranty card included with your product or visit the official Eureka Forbes webເວັບໄຊ.

This image highlights Eureka Forbes' extensive service network, offering support across over 19,000 pincodes, 12-hour toll-free assistance, and video call support within 24 hours, along with doorstep pickup for repairs.
