ຄູ່ມືຜູ້ໃຊ້ HP OmniDesk M02 Tower Desktop

ຮຸ່ນ: TPC-F134-MT

1. ຜະລິດຕະພັນເກີນview

The HP OmniDesk M02 Tower Desktop is a high-performance personal computer designed for business and productivity. It features an AMD Ryzen 7 8700G processor, ample DDR5 RAM, and fast SSD storage, running on Windows 11 Home. This manual provides essential information for setting up, operating, maintaining, and troubleshooting your device.

HP OmniDesk M02 Tower Desktop with key features highlighted

Image 1.1: HP OmniDesk M02 Tower Desktop highlighting its AMD Ryzen 7 8700G processor, Windows 11 operating system, Wi-Fi 6 connectivity, and memory/storage capabilities.

ຄຸນ​ນະ​ສົມ​ບັດ​ທີ່​ສໍາ​ຄັນ​:

  • ໜ່ວຍປະມວນຜົນ: AMD Ryzen 7 8700G (8 Cores, 16 Threads, up to 5.1GHz Max Boost)
  • ໜ່ວຍຄວາມຈຳ: RAM 16GB DDR5 (ສາມາດຂະຫຍາຍໄດ້ສູງສຸດ 64GB)
  • ການເກັບຮັກສາ: 1TB PCIe M.2 SSD, bundled with ADATA 512GB External SSD
  • ລະບົບປະຕິບັດການ: ໜ້າຫຼັກ Windows 11
  • ຮູບພາບ: ປະສົມປະສານ AMD Radeon Graphics
  • ການເຊື່ອມຕໍ່: Wi-Fi 6, Bluetooth, Ethernet (RJ-45)
  • ພອດ: Multiple USB Type-A and Type-C ports, HDMI, DisplayPort, audio jacks
  • Included Peripherals: ແປ້ນພິມແບບມີສາຍ & ຫນູ
ຄຸນສົມບັດຂອງ SSD ພາຍນອກ ADATA SD620

Image 1.2: The ADATA SD620 External SSD, included with the HP OmniDesk M02, highlighting its data transfer speed and MIL-STD shock resistance.

2. ຄໍາແນະນໍາການຕິດຕັ້ງ

Follow these steps to set up your HP OmniDesk M02 Tower Desktop.

2.1 ການຫຸ້ມຫໍ່

  1. ເອົາສ່ວນປະກອບທັງຫມົດອອກຈາກການຫຸ້ມຫໍ່ຢ່າງລະມັດລະວັງ.
  2. Verify that all items are present: HP OmniDesk M02 Tower Desktop, Wired Keyboard, Wired Mouse, Power Cable, and ADATA 512GB External SSD.
  3. Retain packaging materials for future transport or service.

2.2 ການເຊື່ອມຕໍ່ອຸປະກອນຕໍ່

ເຊື່ອມຕໍ່ຈໍພາບ, ແປ້ນພິມ, ເມົາສ໌ ແລະ ອຸປະກອນອື່ນໆຂອງທ່ານກັບພອດທີ່ເໝາະສົມໃນເດັສທັອບ.

Diagram of HP OmniDesk M02 front and rear ports

ຮູບພາບ 2.1: ລາຍລະອຽດ view of the front and rear ports on the HP OmniDesk M02 Tower Desktop, indicating their types and functions.

  • ຈໍພາບ: Connect your monitor to either the HDMI or DisplayPort on the rear of the desktop.
  • ແປ້ນພິມ ແລະເມົາສ໌: Connect the wired keyboard and mouse to any available USB Type-A ports.
  • ພະລັງງານ: ເຊື່ອມຕໍ່ສາຍໄຟເຂົ້າກັບຊ່ອງສຽບໄຟຟ້າຂອງຄອມພິວເຕີຕັ້ງໂຕະ ແລະ ຈາກນັ້ນເຂົ້າກັບປລັກສຽບຝາ.
  • SSD ພາຍນອກ: Connect the ADATA 512GB External SSD to an available USB port.
  • ເຄືອຂ່າຍ (ທາງເລືອກ): ສຳລັບການເຊື່ອມຕໍ່ອິນເຕີເນັດແບບມີສາຍ, ໃຫ້ເຊື່ອມຕໍ່ສາຍ Ethernet ເຂົ້າກັບພອດ RJ-45.

2.3 ການເປີດເຄື່ອງຄັ້ງທຳອິດ

  1. ກົດປຸ່ມເປີດປິດຢູ່ດ້ານຫນ້າຂອງ desktop.
  2. Follow the on-screen instructions to complete the Windows 11 Home setup. This typically involves selecting your region, language, and creating a user account.
  3. Ensure an internet connection is established during setup for updates and account synchronization.

3. ຄໍາແນະນໍາການດໍາເນີນງານ

This section covers basic operation of your HP OmniDesk M02.

3.1 ເປີດ/ປິດ ແລະຣີສະຕາດ

  • ເປີດ: ກົດປຸ່ມເປີດປິດຢູ່ດ້ານຫນ້າຂອງ desktop.
  • ປິດລົງ: ຄລິກທີ່ປຸ່ມ Start ໃນ Windows 11, ຈາກນັ້ນເລືອກ Power > Shut down.
  • ຣີສະຕາດ: ຄລິກທີ່ປຸ່ມ Start, ຈາກນັ້ນເລືອກ Power > Restart.

3.2 ການເຊື່ອມຕໍ່ Wi-Fi ແລະ Bluetooth

  • Wi-Fi: Click the Network icon in the taskbar, select your desired Wi-Fi network, enter the password, and click Connect.
  • Bluetooth: Go to Settings > Bluetooth & devices, ensure Bluetooth is turned on, and then click "Add device" to pair new Bluetooth devices.

3.3 Using Windows 11 and AI Features

Your HP OmniDesk M02 comes with Windows 11 Home, offering a modern interface and integrated AI capabilities through Copilot.

Person using HP OmniDesk M02 with Copilot AI features

Image 3.1: A user interacting with the HP OmniDesk M02, demonstrating the integration of Copilot for enhanced productivity and AI-driven workflows.

  • ເມນູເລີ່ມຕົ້ນ: Access applications, settings, and power options from the centered Start menu.
  • ບັນດາ: Personalize your desktop with widgets for news, weather, and more.
  • Copilot: Utilize the integrated Copilot AI for assistance with tasks, content creation, and system navigation. Access it via the taskbar icon.

4. ບໍາລຸງຮັກສາ

ການບໍາລຸງຮັກສາທີ່ເຫມາະສົມຮັບປະກັນອາຍຸຍືນແລະການປະຕິບັດທີ່ດີທີ່ສຸດຂອງ desktop ຂອງທ່ານ.

4.1 ການທໍາຄວາມສະອາດ

  • ພາຍນອກ: ໃຊ້ຜ້າແພທີ່ອ່ອນໆ ທີ່ບໍ່ມີເສັ້ນດ່າງ dampຖອກດ້ວຍນ້ໍາຫຼືການແກ້ໄຂການທໍາຄວາມສະອາດອ່ອນໆ. ຫຼີກເວັ້ນການສານເຄມີທີ່ຮຸນແຮງ.
  • ຮູ: Periodically clean dust from the ventilation grilles using compressed air to prevent overheating. Ensure the desktop is powered off before cleaning vents.

4.2 ການປັບປຸງຊອບແວ

ອັບເດດລະບົບປະຕິບັດການ ແລະ ໄດຣເວີຂອງທ່ານເປັນປະຈຳເພື່ອຮັບປະກັນຄວາມປອດໄພ ແລະ ປະສິດທິພາບ.

  • ອັບເດດ Windows: Go to Settings > Windows Update and check for available updates.
  • ອັບເດດໄດເວີ: ໄປຢ້ຽມຢາມການສະຫນັບສະຫນູນ HP ຢ່າງເປັນທາງການ website for your model to download the latest drivers for components like graphics and chipset.

4.3 Hardware Upgrades

The HP OmniDesk M02 supports upgrades for RAM and internal storage.

  • RAM: The system supports up to 64GB DDR5 UDIMM RAM.
  • SSD ພາຍໃນ: The system supports up to 4TB PCIe M.2 SSD.
  • ສຳຄັນ: Opening the chassis for upgrades may affect the original manufacturer's warranty. Consult the warranty section for details.

5. ການແກ້ໄຂບັນຫາ

ພາກສ່ວນນີ້ແກ້ໄຂບັນຫາທົ່ວໄປທີ່ທ່ານອາດຈະພົບ.

5.1 ບໍ່ມີພະລັງງານ

  • Ensure the power cable is securely connected to both the desktop and a working power outlet.
  • ກວດເບິ່ງວ່າປລັກສຽບໄຟເຮັດວຽກຫຼືບໍ່ໂດຍການສຽບອຸປະກອນອື່ນ.
  • Verify the power supply unit (PSU) switch (if present) is in the ON position.

5.2 ບໍ່ມີຈໍສະແດງຜົນໃນຈໍສະແດງຜົນ

  • Confirm the monitor is powered on and its input source is correctly selected (HDMI/DisplayPort).
  • Check that the video cable is securely connected to both the desktop and the monitor.
  • ລອງເຊື່ອມຕໍ່ຈໍພາບກັບພອດວິດີໂອອື່ນໃນຄອມພິວເຕີຕັ້ງໂຕະຖ້າມີ.

5.3 ບັນຫາການເຊື່ອມຕໍ່ເຄືອຂ່າຍ

  • Wired: Ensure the Ethernet cable is properly connected and your router/modem is working.
  • Wi-Fi: Verify Wi-Fi is enabled in Windows settings and you are connected to the correct network with the correct password. Restart your router/modem.

6. ຂໍ້ມູນຈໍາເພາະ

Detailed technical specifications for the HP OmniDesk M02 Tower Desktop.

AMD Ryzen 7 8700G processor close-up

ຮູບພາບທີ 6.1: ໄລຍະໃກ້ view of the AMD Ryzen 7 8700G processor, highlighting its core count, thread count, clock speed, and L3 cache.

ອົງປະກອບຂໍ້ມູນຈໍາເພາະ
ໝາຍເລກຕົວແບບTPC-F134-MT
ໂຮງງານຜະລິດAMD Ryzen 7 8700G (8 Cores, 16 Threads, 4.2GHz base, up to 5.1GHz max turbo)
RAM16GB DDR5 UDIMM (4800 MHz), expandable to 64GB
ການເກັບຮັກສາພາຍໃນ1TB PCIe M.2 SSD, expandable to 4TB
ບ່ອນເກັບຂໍ້ມູນພາຍນອກSSD ພາຍນອກ ADATA 512GB (ມາພ້ອມ)
ຮູບພາບປະສົມປະສານ AMD Radeon Graphics
ລະບົບປະຕິບັດການໜ້າຫຼັກ Windows 11
ການເຊື່ອມຕໍ່ໄຮ້ສາຍWi-Fi 6 (802.11ax), Bluetooth
ທ່າເຮືອທາງໜ້າ1x USB Type-C 10Gbps, 1x USB Type-C 5Gbps, 2x USB Type-A 10Gbps, 2x USB Type-A 5Gbps, 1x ຫູຟັງ/ໄມໂຄຣໂຟນຄອມໂບ
Ports ຫລັງ4x USB 2.0 ປະເພດ-A, 1x RJ-45 (Ethernet), 3x ຊ່ອງສຽບສຽງ 3.5 ມມ Combo, 1x HDMI, 1x DisplayPort
ຂະໜາດ (LxWxH)6.10" x 13.27" x 12.40" (15.5 x 33.7 x 31.5 ຊມ)
ນ້ຳໜັກ12.72 lbs (5.77 ກິ​ໂລ​)
ສີສີເທົາ

7. ການຮັບປະກັນແລະການສະຫນັບສະຫນູນ

7.1 ຂໍ້ມູນການຮັບປະກັນ

The HP OmniDesk M02 Tower Desktop comes with a manufacturer's warranty. For this specific configuration, a 1-year warranty on the upgraded RAM and SSD is provided by PCOnline US. All other original components retain the standard 1-year manufacturer's warranty from HP.

ກະລຸນາຮັກສາຫຼັກຖານການຊື້ຂອງທ່ານສໍາລັບການຮຽກຮ້ອງການຮັບປະກັນ.

7.2 ສະຫນັບສະຫນູນດ້ານວິຊາການ

For technical assistance, please refer to the official HP support website or contact their customer service. For issues related to the upgraded RAM or SSD, please contact PCOnline US directly.

ສະ​ຫນັບ​ສະ​ຫນູນ HP​: www.hp.com/support
