DOOGEE Fire 5 Pro ຄູ່ມືຜູ້ໃຊ້ໂທລະສັບ Rugged

1. ບົດແນະນຳ

This manual provides essential information for the safe and efficient use of your DOOGEE Fire 5 Pro Rugged Phone. Please read this manual carefully before using the device to ensure proper operation and to maximize its features. The DOOGEE Fire 5 Pro is designed for durability and performance, featuring a large battery, robust construction, and advanced Android capabilities.

Image: DOOGEE Fire 5 Pro highlighting its 13000mAh battery, 6.6" 90Hz HD+ display, 20GB+128GB memory, and Mediatek Helio G81 Octa-Core chipset.

2. ສິ່ງທີ່ຢູ່ໃນກ່ອງ

ກວດ​ສອບ​ວ່າ​ລາຍ​ການ​ທັງ​ຫມົດ​ແມ່ນ​ມີ​ຢູ່​ໃນ​ຊຸດ​ຜະ​ລິດ​ຕະ​ພັນ​ຂອງ​ທ່ານ​:

• 1 x DOOGEE Fire 5 Pro Rugged Phone
• 1 x ສາຍ USB Type-C
• 1 x ເຄື່ອງສາກ
• 1 x Silk screen printing Protective Film (Pre-applied)
• 1 x ກ່ອງບັນຈຸ
• 1 x ຄູ່ມື / 1 x ບັດຮັບປະກັນ

Image: The DOOGEE Fire 5 Pro phone along with its included accessories: charger, USB cable, and protective film.

3. ອຸປະກອນເກີນview

Familiarize yourself with the physical components of your DOOGEE Fire 5 Pro.

ດ້ານໜ້າ View

ຮູບພາບ: ດ້ານຫນ້າແລະດ້ານຫລັງ view of the DOOGEE Fire 5 Pro, showing the display, front camera, and rear camera module.

ຂ້າງ View ແລະພອດ

ຮູບພາບ: ຂ້າງ view of the DOOGEE Fire 5 Pro, illustrating the power button, volume rocker, and customizable key.

• ປຸ່ມເປີດປິດ: Press and hold to power on/off or restart. Short press to wake/sleep screen.
• ປຸ່ມລະດັບສຽງ: ປັບລະດັບສຽງສື່, ລະດັບສຽງເອີ້ນເຂົ້າ ແລະ ລະດັບສຽງແຈ້ງເຕືອນ.
• Customizable Key: Can be programmed for quick access to specific functions or apps.
• ພອດ USB Type-C: ສໍາລັບການສາກໄຟແລະການໂອນຂໍ້ມູນ.
• Jack ສຽງ 3.5mm: ສໍາລັບການເຊື່ອມຕໍ່ຫູຟັງ.

4. ຕັ້ງຄ່າ

4.1. ການຕິດຕັ້ງແຜ່ນ SIM ແລະບັດ MicroSD

The DOOGEE Fire 5 Pro supports Dual SIM 4G connectivity and expandable storage via a MicroSD card.

1. ຊອກຫາຖາດຊິມກາດຢູ່ດ້ານຂ້າງຂອງອຸປະກອນ.
2. ໃຊ້ເຄື່ອງມືຖອດຊິມທີ່ສະໜອງໃຫ້ເພື່ອເປີດຖາດ.
3. Carefully place your Nano-SIM cards and/or MicroSD card into the designated slots, ensuring correct orientation.
4. ຄ່ອຍໆຍູ້ຖາດກັບເຂົ້າໄປໃນອຸປະກອນຈົນກ່ວາມັນກົດເຂົ້າໄປໃນສະຖານທີ່.

Image: Illustration of how to correctly insert SIM cards and a MicroSD card into the phone's tray.

4.2. ການສາກໄຟເບື້ອງຕົ້ນ ແລະເປີດເຄື່ອງ

ກ່ອນທີ່ຈະໃຊ້ຄັ້ງທໍາອິດ, ມັນແນະນໍາໃຫ້ສາກອຸປະກອນຂອງທ່ານຢ່າງເຕັມທີ່.

1. ເຊື່ອມຕໍ່ສາຍ USB Type-C ກັບຊ່ອງສາກໄຟຂອງໂທລະສັບ ແລະອີກສົ້ນກັບສາຍສາກທີ່ສະໜອງໃຫ້.
2. Plug the charger into a power outlet. The phone supports 18W fast charging.
3. Once sufficiently charged, press and hold the Power Button until the DOOGEE logo appears to power on the device.

Image: The DOOGEE Fire 5 Pro connected to its charger via the USB Type-C port.

5. ປະຕິບັດການອຸປະກອນຂອງທ່ານ

5.1. ລະບົບປະຕິບັດການ Android 15

Your DOOGEE Fire 5 Pro runs on the latest Android 15 OS, offering enhanced security, privacy features, and a smooth user experience.

ຮູບພາບ: ຫຼາຍກວ່າview of Android 15 OS features including App Clone, App Lock, System Manager, Fingerprint Gestures, Game Mode, Kids Mode, Dynamic Capsule, Peek Proof, and Lift to Wake.

5.2. Gemini AI Integration

The intelligent Gemini AI engine enhances various functions, including content creation, image recognition, and smart scheduling.

Image: Visual representation of Gemini AI capabilities such as Content Creation, Image Analysis, Code Development, Language Learning, Smart Assistant, and Gemini Live.

5.3. ຟັງຊັນກ້ອງຖ່າຍຮູບ

Capture clear photos and videos with the 13MP AI main camera and 8MP front camera.

Image: A landscape photo taken with the 13MP main camera of the DOOGEE Fire 5 Pro.

Image: Multiple selfies taken with the 8MP front camera of the DOOGEE Fire 5 Pro.

Image: Display of various camera modes available, including Night Mode, Portrait Mode, Pro Mode, Time-lapse, Beauty Mode, and Panoramic Mode.

Image: Features of the Google Intelligent Camera, such as Homework analysis, Text extraction and translation, Plant and animal identification, E-commerce search, and View ຊອກຫາ.

ຮູບພາບ: Examples of AI Recognition in the camera, identifying various scenes and objects.

6. ຄຸນສົມບັດຄວາມທົນທານ

The DOOGEE Fire 5 Pro is built to withstand harsh environments, meeting industry-leading durability standards.

• IP68/IP69K Rating: Certified for dust and water resistance. It can withstand immersion in water up to 1.5 meters for 30 minutes and is protected against high-pressure, high-temperature water jets.
• MIL-STD-810H: Complies with military standards for resistance against drops, shocks, and extreme temperatures.

Image: Visuals showing the phone passing a 1.5m high strength drop test, soaking in 1.5m deep water for 30 minutes, and demonstrating resistance to dust.

Image: The DOOGEE Fire 5 Pro partially submerged in water, showcasing ຄວາມສາມາດໃນການກັນນ້ຳຂອງມັນ.

Image: The DOOGEE Fire 5 Pro covered in dirt, demonstrating its dustproof design.

7. ການຄຸ້ມຄອງຫມໍ້ໄຟ

The DOOGEE Fire 5 Pro is equipped with a large 13000mAh battery for extended usage.

• ຄວາມອາດສາມາດ: 13000mAh for prolonged use.
• ການສາກໄວ: Supports 18W fast charging for quick power-ups.
• OTG Reverse Charging: Use your phone as a power bank to charge other devices.

Image: Diagram illustrating the 13000mAh battery capacity and 18W fast charging capability.

Image: Statistics showing estimated battery life: 205 hours music playing, 43 hours video watching, 94 hours calling, and 75 days standby.

8. ການເກັບຮັກສາແລະການປະຕິບັດ

Experience smooth performance and ample ການເກັບຮັກສາສໍາລັບຄວາມຕ້ອງການຂອງທ່ານທັງຫມົດ.

• ໜ່ວຍປະມວນຜົນ: MediaTek Helio G81 Octa-Core processor for efficient multitasking and app performance.
• RAM: 20GB (4GB physical + 16GB virtual expansion) for seamless operation.
• ການເກັບຮັກສາພາຍໃນ: 128GB ROM for your apps, photos, and files.
• ການເກັບຮັກສາທີ່ຂະຫຍາຍໄດ້: Supports up to 2TB TF card expansion (TF card needs to be purchased separately).

Image: Diagram illustrating the Mediatek Helio G81 Octa-Core 12nm chipset, emphasizing its processing power.

Image: Visual representation of the 20GB Max RAM (4GB Basic + 16GB Virtual RAM) and 128GB ROM, with support for 2TB expandable memory.

9. ຈໍສະແດງຜົນ

The DOOGEE Fire 5 Pro features a vibrant and responsive display.

• ຂະໜາດ: 6.6-inch HD+ IPS Display.
• ອັດຕາການໂຫຼດຂໍ້ມູນຄືນໃໝ່: 90Hz for smooth visuals.
• ຄວາມລະອຽດ: ຂະ ໜາດ 720 x 1612 ພິກະເຊນ.
• ສີ: 16.7 million screen colors.
• ອັດຕາສ່ວນໜ້າຈໍຕໍ່ຮ່າງກາຍ: 85%.
• ໂໝດມືດ: Available for comfortable viewing.

Image: The 6.6-inch 90Hz HD+ IPS display of the DOOGEE Fire 5 Pro, highlighting its refresh rate, resolution, screen color, and screen-to-body ratio.

10. ການເຊື່ອມຕໍ່

Stay connected with versatile network and data options.

• ຊິມຄູ່ 4G: Supports two SIM cards for flexible communication.
• NFC: For convenient contactless payments and quick data transfers.
• GPS: Built-in GPS for accurate navigation.
• Wi-Fi: ການເຊື່ອມຕໍ່ Wi-Fi ມາດຕະຖານ.
• Bluetooth: ສໍາລັບການເຊື່ອມຕໍ່ອຸປະກອນເສີມໄຮ້ສາຍ.

11. ບໍາລຸງຮັກສາ

To ensure the longevity and optimal performance of your DOOGEE Fire 5 Pro, follow these maintenance guidelines:

• ທໍາຄວາມສະອາດ: ໃຊ້ອ່ອນ, ງamp ຜ້າເພື່ອເຮັດຄວາມສະອາດອຸປະກອນ. ຫຼີກເວັ້ນການສານເຄມີທີ່ຮຸນແຮງຫຼືວັດສະດຸຂັດ.
• ການເປີດເຜີຍນ້ໍາ: While waterproof, ensure all ports are properly sealed before exposing the phone to water. Rinse with fresh water after exposure to saltwater or other liquids.
• ອຸນຫະພູມ: Avoid exposing the device to extreme temperatures (very hot or very cold) for extended periods.
• ອັບເດດຊອບແວ: ກວດສອບ ແລະຕິດຕັ້ງການອັບເດດຊອບແວເປັນປະຈຳເພື່ອຮັບປະກັນປະສິດທິພາບ ແລະຄວາມປອດໄພທີ່ດີທີ່ສຸດ.
• ການເກັບຮັກສາ: Keep internal storage clear by regularly deleting unnecessary files and apps. Utilize expandable storage for media.

12. ການແກ້ໄຂບັນຫາ

ຖ້າ​ຫາກ​ທ່ານ​ພົບ​ບັນ​ຫາ​ກັບ​ອຸ​ປະ​ກອນ​ຂອງ​ທ່ານ​, ເບິ່ງ​ວິ​ທີ​ແກ້​ໄຂ​ທົ່ວ​ໄປ​ດັ່ງ​ຕໍ່​ໄປ​ນີ້​:

• ອຸປະກອນບໍ່ຕອບສະໜອງ: ກົດປຸ່ມເປີດປິດຄ້າງໄວ້ປະມານ 10-15 ວິນາທີເພື່ອບັງຄັບໃຫ້ຣີສະຕາດ.
• ບັນຫາການສາກໄຟ: ກວດໃຫ້ແນ່ໃຈວ່າສາຍສາກ ແລະອະແດັບເຕີເຊື່ອມຕໍ່ຢ່າງປອດໄພ ແລະ ບໍ່ເສຍຫາຍ. ລອງປລັກສຽບ ຫຼືສາຍສາກອື່ນ.
• ການເຊື່ອມຕໍ່ເຄືອຂ່າຍ: ກວດສອບວ່າຊິມກາດຂອງທ່ານຖືກໃສ່ຢ່າງຖືກຕ້ອງແລ້ວ. ເປີດ ແລະ ປິດໂໝດເຮືອບິນ. ປິດອຸປະກອນຄືນໃໝ່. ກວດສອບການຕັ້ງຄ່າຂໍ້ມູນມືຖືຂອງທ່ານ.
• ແອັບຂັດຂ້ອງ: ລຶບລ້າງແຄສ ແລະຂໍ້ມູນຂອງແອັບທີ່ມີບັນຫາໃນການຕັ້ງຄ່າ > ແອັບ. ຖ້າບັນຫາຍັງຄົງຢູ່, ຖອນການຕິດຕັ້ງ ແລະຕິດຕັ້ງແອັບຄືນໃໝ່.
• ປະສິດທິພາບຊ້າ: Close unnecessary background apps. Clear system cache. Consider a factory reset if performance issues are severe (back up your data first).
• Water Damage Concerns: If the device has been exposed to water and is malfunctioning, ensure all ports are dry. Do not attempt to charge the device if water is suspected in the charging port.

13. ຂໍ້ມູນຈໍາເພາະ

Detailed technical specifications for the DOOGEE Fire 5 Pro:

14. ການຮັບປະກັນແລະການສະຫນັບສະຫນູນ

DOOGEE provides comprehensive support for your device:

• ການຄໍ້າປະກັນຄືນເງິນ 30 ວັນ: ຖ້າທ່ານບໍ່ພໍໃຈກັບການຊື້ຂອງທ່ານ, ທ່ານອາດຈະມີສິດໄດ້ຮັບເງິນຄືນພາຍໃນ 30 ມື້.
• ການຮັບປະກັນ 2 ປີຈໍາກັດ: ອຸ​ປະ​ກອນ​ຂອງ​ທ່ານ​ແມ່ນ​ໄດ້​ຮັບ​ການ​ຄຸ້ມ​ຄອງ​ໂດຍ​ການ​ຮັບ​ປະ​ກັນ​ທີ່​ຈໍາ​ກັດ 2 ປີ​ຕໍ່​ຕ້ານ​ຄວາມ​ຜິດ​ພາດ​ການ​ຜະ​ລິດ​.
• 24/7 ສະຫນັບສະຫນູນອອນໄລນ໌: Access to one-on-one online customer service for any queries or issues.

Image: Information regarding DOOGEE's customer service, including 30-day money-back guarantee, 2-year limited warranty, and 24/7 online support.
