ຄູ່ມືຜູ້ໃຊ້ເຄື່ອງເຮັດປ້າຍ HPRT T260LR

1. ບົດແນະນຳ

This manual provides detailed instructions for the HPRT T260LR Label Maker. Please read this manual thoroughly before using the device to ensure proper operation and to maximize its lifespan. The HPRT T260LR is a versatile thermal label printer designed for various labeling needs, offering ink-free printing and smart label recognition.

Image 1.1: The HPRT T260LR Label Maker shown with several examples of printed labels and a roll of blank thermal labels. This image illustrates the compact design of the label maker and the variety of labels it can produce, including those with text, barcodes, and icons. Product reference: 2184864564880.

2. ຄຸນນະສົມບັດທີ່ສໍາຄັນ

The HPRT T260LR Label Maker offers a range of features designed for efficiency and convenience:

• All-in-One Labeling: Provides comprehensive solutions for various labeling tasks, from address stamps to organizing storage bins.
• ການເຊື່ອມຕໍ່ Bluetooth: Enables wireless printing directly from mobile phones via the HereLabel app.
• Smart Label Recognition: Automatically identifies label sizes, streamlining the printing process and minimizing waste with automatic paper feed and rollback.
• ການພິມດ້ວຍຄວາມຮ້ອນແບບບໍ່ໃຊ້ໝຶກ: Utilizes thermal technology, eliminating the need for ink and delivering clear prints. HPRT labels are waterproof, oil-resistant, and removable.
• Portable ແລະກະທັດຮັດ: Easy to carry, making it suitable for home, office, or on-the-go use.

ຮູບພາບ 2.1: ຫຼາຍກວ່າview of the HPRT T260LR Thermal Label Maker, emphasizing its core features such as RFID identification, compact design, ink-free operation, fast printing, long battery life, and ease of use.

3. ຄູ່ມືການຕິດຕັ້ງ

3.1. ການຕິດຕັ້ງແຜ່ນປ້າຍຊື່

Follow these steps to correctly install the label tape into your HPRT T260LR Label Maker:

1. ຂັ້ນຕອນທີ 1: Open the cover by gently pulling it outward with both hands.
2. ຂັ້ນຕອນທີ 2: Lift and adjust the paper limiter upward, then lock it into place.
3. ຂັ້ນຕອນທີ 3: Place the label paper roll to the right, ensuring the printing side is facing up.
4. ຂັ້ນຕອນທີ 4: Pull the label paper forward, close the lid, and then press and hold the power button for 3 seconds to turn on the device.

Image 3.1: A visual step-by-step guide demonstrating the process of installing label tape into the HPRT T260LR Label Maker, from opening the cover to loading the paper and closing the lid.

3.2. ການຕິດຕັ້ງແອັບຯ ແລະການເຊື່ອມຕໍ່ Bluetooth

To use your label maker wirelessly, install the HereLabel app and connect via Bluetooth:

1. ຂັ້ນຕອນທີ 1: Scan the QR code provided in the image or visit https://hm.hprt.com/en/download/?from=T21 to install the "HereLabel" app on your mobile device.
2. ຂັ້ນຕອນທີ 2: Open the HereLabel app and tap on the "Not connected" status to initiate the connection process.
3. ຂັ້ນຕອນທີ 3: In the list of searched Bluetooth devices, find "HM-T260LR-XXXX" (where XXXX is a unique identifier) and tap to connect.
4. ຂັ້ນຕອນທີ 4: Once connected, tap "Current Consumables" and then choose "Use templates" or tap "New" to start designing.
5. ຂັ້ນຕອນທີ 5: Tap "Text" to input your desired text for the label.
6. ຂັ້ນຕອນທີ 6: After editing your label, set the number of copies and tap "Print" to begin printing.

Image 3.2: A visual guide detailing the six steps required to install the HereLabel app, connect the label maker via Bluetooth, and initiate the printing process from your mobile device.

Image 3.3: The HereLabel app interface shown on a smartphone, demonstrating its use for connecting to the HPRT T260LR label maker and customizing labels. The image also shows various labels printed using the device.

4. ການດໍາເນີນງານ

4.1. Using the HereLabel App for Customization

The HereLabel app provides extensive options for designing and customizing your labels:

• ການປ້ອນຂໍ້ຄວາມ: Easily add and format text.
• Barcode & QR Code Generation: Create various types of barcodes and QR codes.
• Icon Integration: Choose from a library of icons to enhance your labels.
• Date & Line Tools: Add dates and design elements like lines and shapes.
• ໜ້າທີ່ຂອງຕາຕະລາງ: Incorporate tables for structured information.

Image 4.1: The HereLabel app's customization interface, displaying various tools available for designing labels, including options for text, barcodes, QR codes, icons, dates, lines, shapes, and tables.

Image 4.2: Several smartphone screens illustrating the rich selection of iconic designs and customization options available within the HereLabel app, allowing for personalized label creation. Product reference: 2184864564880.

4.2. Smart Label Recognition

The HPRT T260LR features smart label recognition, which automatically detects the size of the loaded label paper. This function ensures accurate printing and minimizes label waste. It is compatible only with HPRT Thermal Label Paper.

Image 4.3: A graphic representation of the Smart RFID Label Recognition feature, highlighting its benefits such as easy template detection and zero label wastage due to automatic paper rollback.

Image 4.4: The HereLabel app interface showing the 'Current consumables' screen, which indicates the automatic recognition of label dimensions. The label maker and various labels are also visible.

4.3. Supported Label Sizes and Applications

The HPRT T260LR supports various label widths from 0.8" to 2" (20-50mm), accommodating different label shapes and sizes for diverse applications.

Image 4.5: An illustration of the various label sizes and shapes compatible with the HPRT T260LR, such as cable labels, special-shaped labels, solid color labels, pattern labels, and circular labels.

Image 4.6: The HPRT T260LR label maker, shown with a smartphone running the HereLabel app, and various label rolls and printed labels, illustrating its capability to support multiple label sizes.

Image 4.7: A collage showcasing diverse applications for the labels created by the HPRT T260LR, including logos, thank-you stickers, address labels, price labels for food items, gift tags, and name tags for personal items.

ຮູບພາບ 4.8: ຕົວຢ່າງamples of specialized labels for bakery products, coffee cups, and craft items, demonstrating the versatility of the HPRT T260LR for various business and personal uses.

Image 4.9: Illustrations of label applications for organizing kitchen and pantry items, customizing gifts, labeling kids' belongings, and general household organization.

ຮູບພາບ 4.10: ຕົວຢ່າງamples of labels used for file organization, general office organization (e.g., drawer labels), and document identification, showcasing the printer's utility in a professional setting.

5. ບໍາລຸງຮັກສາ

To ensure optimal performance and longevity of your HPRT T260LR Label Maker, regular maintenance is recommended:

• ທໍາ​ຄວາມ​ສະ​ອາດ​ຫົວ​ພິມ​: ເຊັດຫົວພິມຄວາມຮ້ອນດ້ວຍສຳລີຄ່ອຍໆ.ampened with isopropyl alcohol. Ensure the device is turned off and cooled down before cleaning. Allow it to dry completely before use.
• ທໍາ​ຄວາມ​ສະ​ອາດ​ພາຍ​ນອກ​: Use a soft, dry cloth to wipe the exterior of the label maker. Avoid using abrasive cleaners or solvents.
• ການເກັບຮັກສາ: ເກັບຮັກສາເຄື່ອງເຮັດປ້າຍໄວ້ໃນບ່ອນທີ່ເຢັນ, ແຫ້ງ ແລະ ຫ່າງຈາກແສງແດດໂດຍກົງ ແລະ ອຸນຫະພູມສູງສຸດ.
• Label Roll Handling: Always use high-quality HPRT thermal labels. Store label rolls in their original packaging to protect them from dust and moisture.

6. ການແກ້ໄຂບັນຫາ

If you encounter issues with your HPRT T260LR Label Maker, refer to the following common problems and solutions:

7. ຂໍ້ມູນຈໍາເພາະ

Key technical specifications for the HPRT T260LR Label Maker:

• ຕົວແບບ: T260LR
• ເຕັກໂນໂລຊີການພິມ: ການພິມຄວາມຮ້ອນ
• ການເຊື່ອມຕໍ່: Bluetooth
• Compatible Label Width: 0.8" - 2" (20ມມ - 50ມມ)
• ຄວາມເຂົ້າກັນໄດ້ຂອງແອັບຯ: HereLabel (available on app stores)
• ຄຸນນະສົມບັດພິເສດ: Smart Label Recognition, Ink-Free Printing, Automatic Paper Feed/Rollback
• ວັນທີທໍາອິດທີ່ມີ: ວັນທີ 18 ກໍລະກົດ 2024
• ASIN: B0D9NKJTY1

Image 7.1: A roll of HPRT Thermal Labels, specifically 200 labels per roll, measuring 1.97 x 1.18 inches (50mm x 30mm), highlighting their compatibility with HPRT T20/T260LR label makers.

8. ການຮັບປະກັນແລະການສະຫນັບສະຫນູນ

For warranty information, technical support, or further assistance, please refer to the official HPRT website or contact HPRT customer service. Keep your purchase receipt for warranty claims.

ທາງການ Webເວັບໄຊ: www.hprt.com

ດາວໂຫລດແອັບ:: https://hm.hprt.com/en/download/?from=T21
