1. ບົດແນະນຳ
This manual provides essential instructions for the safe and effective use of your eeTao 5V AC/DC USB Power Adapter. This adapter is designed to provide reliable power to compatible Cubii under-desk elliptical exercise machines, including models JR1+ F4A2, JR2+ Cubii GO, and Cubii Pro F3A1. Please read this manual thoroughly before use and retain it for future reference.
Image 1.1: The eeTao USB Power Adapter (implied by connection) with a Cubii elliptical machine and a smartphone displaying fitness data. This adapter is designed for charging such devices.
2. ຄໍາແນະນໍາການຕິດຕັ້ງ
Follow these steps to properly set up your eeTao 5V AC/DC USB Power Adapter:
- ຖອດອະແດບເຕີອອກ: Carefully remove the power adapter and any included cables from its packaging.
- Identify Adapter and Cable: The package includes the USB plug end 5V AC/DC adapter. You will need a compatible USB cable (e.g., USB-A to Micro-USB or USB-A to USB-C) for your Cubii device.
- Connect the Cable to Adapter: Insert the USB-A end of your charging cable into the USB port on the eeTao power adapter.
- ສຽບໃສ່ປລັກສຽບໄຟ: Extend the foldable prongs on the adapter and plug it into a standard 100-240VAC 50/60Hz wall outlet.
- ເຊື່ອມຕໍ່ຫາອຸປະກອນ: Connect the other end of the USB cable (e.g., Micro-USB or USB-C) to the charging port of your compatible Cubii elliptical exercise machine.
- ຢືນຢັນການເຊື່ອມຕໍ່: Ensure all connections are secure. Your Cubii device should indicate that it is receiving power or charging according to its own indicators.
Image 2.1: The eeTao USB Power Adapter, showing its compact design and foldable AC prongs. The USB output port is located on the side.
ຮູບພາບ 2.2: ຕົວຢ່າງample of a USB-A to Micro-USB charging cable, commonly used with compatible Cubii devices. Ensure your cable matches your device's port.
3. ຄໍາແນະນໍາການດໍາເນີນງານ
The eeTao 5V AC/DC USB Power Adapter is designed for simple operation:
- ເປີດ: Once connected to a power outlet and your Cubii device, the adapter will automatically begin supplying power. There is no on/off switch on the adapter itself.
- ຕົວຊີ້ບອກການສາກໄຟ: Refer to your Cubii elliptical machine's user manual for specific charging indicators (e.g., LED lights, screen display).
- ຕັດການເຊື່ອມຕໍ່: To disconnect, first unplug the adapter from the wall outlet, then disconnect the USB cable from your Cubii device.
4. ບໍາລຸງຮັກສາ
Proper care ensures the longevity and safe operation of your power adapter:
- ທໍາຄວາມສະອາດ: ຕັດເຊື່ອມຕໍ່ອະແດບເຕີຈາກແຫຼ່ງພະລັງງານທັງໝົດກ່ອນທີ່ຈະທໍາຄວາມສະອາດ. ໃຊ້ຜ້າປຽກອ່ອນໆເຊັດດ້ານນອກ. ຢ່າໃຊ້ນໍ້າສະອາດ ຫຼືສານລະລາຍ.
- ການເກັບຮັກສາ: Store the adapter in a cool, dry place away from direct sunlight and moisture when not in use. Avoid wrapping the cable too tightly around the adapter to prevent damage.
- ການກວດກາ: Periodically inspect the adapter and cable for any signs of damage, such as frayed wires, cracked casing, or bent prongs. If damage is observed, discontinue use immediately.
5. ການແກ້ໄຂບັນຫາ
If you encounter issues with your power adapter, refer to the following common solutions:
| ບັນຫາ | ສາເຫດທີ່ເປັນໄປໄດ້ | ການແກ້ໄຂ |
|---|---|---|
| ອຸປະກອນບໍ່ໄດ້ສາກໄຟ/ເປີດເຄື່ອງ. |
|
|
| ອະແດັບເຕີຮູ້ສຶກອົບອຸ່ນໃນເວລາໃຊ້. | ການດໍາເນີນງານປົກກະຕິ. | A slight warmth is normal during operation. If the adapter becomes excessively hot, disconnect it immediately and contact customer support. |
| Adapter suddenly stops working. |
|
The adapter features built-in safety protections. Disconnect the adapter from the power source and the device. Wait a few minutes, then reconnect. If it still does not work, there might be an internal fault or a persistent issue with the connected device. Contact customer support. |
6. ຂໍ້ມູນຈໍາເພາະຂອງຜະລິດຕະພັນ
Detailed specifications for the eeTao 5V AC/DC USB Power Adapter:
ຮູບພາບ 6.1: ດ້ານຫລັງ view of the eeTao power adapter, displaying technical specifications such as input voltage (100-240V AC), output (5V DC), and safety certifications (UL Listed, CE, RoHS).
- ຍີ່ຫໍ້: eeTao
- ໝາຍເລກຕົວແບບ: Cubii JR1+ F4A2 Exercise Machine Adapter
- ການປ້ອນຂໍ້ມູນ Voltage: 100-240VAC, 50/60Hz
- ຜົນໄດ້ຮັບ Voltage: 5V DC
- Ampອາຍຸ: 2 Amps
- ປະເພດຕົວເຊື່ອມຕໍ່: USB (requires compatible USB cable)
- ອຸປະກອນທີ່ເຂົ້າກັນໄດ້: Cubii Under Desk Elliptical Exercise Machine (JR1+ F4A2, JR2+ Cubii GO, Cubii Pro F3A1)
- ຄຸນນະສົມບັດພິເສດ: ເກີນ Voltagການປ້ອງກັນ e (OVP), ການປ້ອງກັນກະແສໄຟຟ້າເກີນ (OCP), ການປ້ອງກັນວົງຈອນສັ້ນ (SCP)
- ການຢັ້ງຢືນ: UL Listed, CE, CCC, RoHS
- ສີ: ດຳ
- ນ້ໍາຫນັກລາຍການ: 2.89 ອອນ
- ຂະໜາດແພັກເກດ: 4.25 x 3.5 x 1.5 ນິ້ວ
7. ຂໍ້ມູນການຮັບປະກັນ
Your eeTao 5V AC/DC USB Power Adapter is covered by the following warranty:
- ນະໂຍບາຍການຄືນເງິນ: 30 days refund from the date of purchase.
- ນະໂຍບາຍການແລກປ່ຽນ: 24 months exchange from the date of purchase for manufacturing defects.
ກະລຸນາຮັກສາຫຼັກຖານການຊື້ຂອງທ່ານສໍາລັບການຮຽກຮ້ອງການຮັບປະກັນ.
8. ການຊ່ວຍເຫຼືອລູກຄ້າ
For any questions, concerns, or technical assistance regarding your eeTao 5V AC/DC USB Power Adapter, please contact eeTao customer support through the retailer's platform where the product was purchased. Provide your product model number and purchase details for efficient service.
