dyplay Urban Traveller Active Noise Cancelling Headphones User Manual

1. ຜະລິດຕະພັນເກີນview

The dyplay Urban Traveller Active Noise Cancelling Headphones are designed to provide an immersive audio experience with advanced noise reduction capabilities. Featuring a comfortable over-ear design, these headphones are suitable for extended use during travel, work, or daily commutes. They offer both wireless Bluetooth and wired connectivity options, ensuring versatility across various devices.

Figure 1.1: dyplay Urban Traveller Active Noise Cancelling Headphones.

ຄຸນ​ນະ​ສົມ​ບັດ​ທີ່​ສໍາ​ຄັນ​:

• 2020 Upgraded Dual-Mic ANC Technology: Significantly reduces background noise up to 32dB, ideal for noisy environments.
• Soft Leather Earpads & Foldable Design: Protein leather earpads for comfort, 90° swiveling rotatable design for portability.
• Built-in Microphone & Bluetooth: High-quality microphone for calls and hands-free operation with Bluetooth connectivity.
• ຊີວິດຫມໍ້ໄຟຍາວ: Up to 24 hours of playtime on a single charge (500mAh Lithium battery).
• Amazing Sound with Hi-Fi Technology: Large 40mm driver units and CSR Bluetooth ensure powerful deep bass and clear sound quality.
• ການສາກໄວ USB-C: Convenient and quick charging.
• APTX Support: For enhanced audio quality over Bluetooth.

2. ມີຫຍັງຢູ່ໃນກ່ອງ?

Upon opening your dyplay Urban Traveller headphones package, you should find the following items:

• dyplay Urban Traveller Active Noise Cancelling Headphones
• ກະເປົາຖືສີດຳ
• 3.5 mm AUX Cable (Audio Cable)
• USB-C Charging Cable (Data Line)
• ຄູ່ມືຜູ້ໃຊ້ (ຄຳແນະນຳ)
• Quality Control Information Card

Figure 2.1: Package Contents of dyplay Urban Traveller Headphones.

The included carrying pouch is made of a durable, canvas-like material, offering good protection for your headphones.

3. Product Features & Controls

The dyplay Urban Traveller headphones feature a sleek matte grey finish with red accents, providing a premium look and feel. The design prioritizes comfort and portability.

Figure 3.1: Key Features of dyplay Urban Traveller Headphones.

ການອອກແບບທາງກາຍະພາບ:

• ຫູຟັງ: Super soft, medium memory foam material for comfortable wearing.
• ສາຍພັນຫົວ: Features a soft, cushioned material for comfort on the head.
• ຄວາມສາມາດປັບໄດ້: Metal adjustable sliders on the sides allow for a wide range of fit, accommodating various head sizes.
• ການອອກແບບແບບພັບ: Headphones fold flat and also collapse into a compact size for easy portability and storage, making them ideal for travel.
• L/R Indicators: Orange 'L' and 'R' markings inside the earcups for easy identification of left and right sides.
• ພາຍນອກ: The outside of each ear cup features an orange mesh metal material, adding a distinctive aesthetic touch.

ການຄວບຄຸມ ແລະພອດ:

• Earcup ຊ້າຍ:
  • ANC (Active Noise Cancelling) button/switch.
  • ຊ່ອງສຽບສຽງ 3.5 ມມ ສຳລັບການເຊື່ອມຕໍ່ແບບມີສາຍ.
• Earcup ຂວາ:
  • ພອດສາກໄຟ USB-C.
  • Volume Up (+) and Volume Down (-) buttons.
  • Power/Multifunction button.
  • ໄຟຕົວຊີ້ວັດຫມໍ້ໄຟ.
• ໄມໂຄຣໂຟນ: Located on each earcup for calls and ANC functionality.

4. ຄູ່ມືການຕິດຕັ້ງ

ການຈັບຄູ່ Bluetooth:

1. ເປີດ: Press and hold the Power/Multifunction button on the right earcup until you hear a voice prompt indicating "Power On" and "Bluetooth Pairing".
2. ເປີດໃຊ້ Bluetooth: Ensure Bluetooth is enabled on your smartphone or other device.
3. ຊອກຫາ ອຸປະກອນ: On your device's Bluetooth settings, search for "dyplay urban traveller" in the list of available devices.
4. ເຊື່ອມຕໍ່: Select "dyplay urban traveller" to initiate the pairing process. Confirm any pairing requests on your device.
5. ການຢືນຢັນ: Once successfully paired, the headphones will provide an audible confirmation. The connection is typically fast and reliable, reconnecting automatically when powered on within range of a previously paired device.

ການເຊື່ອມຕໍ່ສາຍ:

For a wired connection, simply plug one end of the included 3.5mm AUX cable into the audio jack on the left earcup of the headphones and the other end into your audio source. This allows for unlimited playback time without relying on battery power.

5. ຄໍາແນະນໍາການດໍາເນີນງານ

ການດໍາເນີນງານພື້ນຖານ:

• ເປີດ/ປິດ: Use the Power/Multifunction button on the right earcup.
• ການຄວບຄຸມລະດັບສຽງ: ໃຊ້ປຸ່ມລະດັບສຽງຂຶ້ນ (+) ແລະ ລະດັບສຽງລົງ (-) ຢູ່ເທິງຫູຟັງເບື້ອງຂວາ.
• ການຄວບຄຸມການຕິດຕາມ: These buttons can also be used to skip or rewind songs (specific press patterns may apply, refer to quick start guide for details).
• ການຄວບຄຸມການໂທ: The multifunction button allows for hands-free calls (answer/end calls).

Active Noise Cancelling (ANC) Function:

The ANC feature significantly reduces ambient background noise, allowing for a more focused listening experience. It is particularly effective against low-frequency sounds like engine hums or air conditioning noise.

Figure 5.1: Active Noise Cancelling Effectiveness.

• ກຳລັງເປີດໃຊ້ ANC: Use the dedicated ANC switch on the left earcup.
• ປະສິດທິຜົນ: The dual-mic feedforward + feedback ANC technology reduces noise up to 32dB.
• ໝາຍເຫດ: The ANC function remains active until manually switched off or the battery is depleted. Be mindful of turning it off when not in use to conserve battery.

6. ປະສິດທິພາບສຽງ

The dyplay Urban Traveller headphones deliver a high-fidelity audio experience, suitable for various types of content, from music to podcasts and movies.

Figure 6.1: Immersive Audio Experience.

• ຄຸນະພາບສຽງ: Features a nice and crisp sound, especially in the highs. The bass is good without being overpowering, providing a balanced audio profile.
• ປະລິມານ: Capable of sufficient volume levels; users typically do not need to exceed halfway volume for a satisfying experience.
• Movie Watching: Provides a good overall range and strong bass for surround sound effects, enhancing the movie-watching experience.
• Podcast Listening: Voices are clear, especially when ANC is active, making podcasts enjoyable.

ປະສິດທິພາບໄມໂຄຣໂຟນ:

While the headphones are equipped with dual microphones for calls, feedback from recipients indicates that the voice may sound slightly muffled. However, the incoming audio quality for the user remains clear.

7. ຄວາມສະດວກສະບາຍ ແລະການອອກແບບ

The dyplay Urban Traveller headphones are designed with user comfort and portability in mind.

Figure 7.1: Upgraded Soft Protein Ear Cushions.

• Earcup Comfort: The earcups are very comfortable, though they may not completely cover all ear sizes. They tend to cause only slight warmth after prolonged use.
• Headband Comfort: The headband, while cushioned, may cause slight discomfort after extended use for some individuals. This may improve with further breaking in.
• ການພົກພາ: The headphones fold flat and also fold up compactly, making them easy to store in the included carrying pouch and convenient for travel.

Figure 7.2: Foldable Design for Easy Portability.

8. ອາຍຸການໃຊ້ງານຂອງແບັດເຕີຣີ ແລະ ການສາກໄຟ

The dyplay Urban Traveller headphones are equipped with a 500mAh Lithium battery, offering substantial playtime and convenient charging options.

• ເວລາຫຼິ້ນ: ເວລາຫຼິ້ນດົນເຖິງ 24 ຊົ່ວໂມງດ້ວຍການສາກຄັ້ງດຽວ.
• ເວລາສາກໄຟ: Less than 3 hours for a full charge.
• ຊ່ອງສາກໄຟ: USB-C for fast charging.
• ເວລາສະແຕນບາຍ: ສູງສຸດ 500 ຊົ່ວໂມງ.
• ANC Only Playtime: ສູງສຸດ 24 ຊົ່ວໂມງ.
• Music Only Playtime: ສູງສຸດ 15 ຊົ່ວໂມງ.
• ANC + Music Playtime: ສູງສຸດ 12 ຊົ່ວໂມງ.

The battery indicator light on the right earcup provides a visual cue for the remaining battery life.

9. ການແກ້ໄຂບັນຫາ

ບັນຫາທົ່ວໄປ ແລະການແກ້ໄຂ:

• ບັນຫາການເຊື່ອມຕໍ່:
  • Ensure headphones are powered on and in pairing mode.
  • ກວດ​ສອບ​ວ່າ Bluetooth ເປີດ​ໃຊ້​ງານ​ຢູ່​ໃນ​ອຸ​ປະ​ກອນ​ຂອງ​ທ່ານ.
  • ລອງລືມອຸປະກອນໃນການຕັ້ງຄ່າ Bluetooth ຂອງໂທລະສັບຂອງທ່ານ ແລະ ຈັບຄູ່ຄືນໃໝ່.
  • ໃຫ້ແນ່ໃຈວ່າຫູຟັງມີແບັດເຕີຣີພຽງພໍ.
• Muffled Sound During Calls (for recipient):
  • While the headphones provide clear audio to the user, the microphone quality for the person on the other end may sometimes be muffled. Ensure the microphones are not obstructed.
• Headband Discomfort:
  • If the headband causes discomfort after extended use, try adjusting the fit or taking short breaks. The material may soften with continued use.
• ຟັງຊັນ ANC:
  • Ensure the ANC switch on the left earcup is in the 'ON' position.
  • Note that ANC is most effective against consistent low-frequency noises and may not completely block out voices or sudden, sharp sounds.

10. ຂໍ້ມູນຈໍາເພາະ

11. ການຮັບປະກັນແລະການສະຫນັບສະຫນູນ

dyplay offers a comprehensive warranty and support for your Urban Traveller headphones:

• 30-Day Worry-Free Refund & Replacement: If you are unsatisfied with the product, you can request a refund or replacement within 30 days of purchase.
• ການຮັບປະກັນ 1 ປີ: ຜະລິດຕະພັນໄດ້ຮັບການຮັບປະກັນ 1 ປີ ນັບຈາກວັນທີ່ຊື້.
• 24-Hour Online Support: For any issues or inquiries, dyplay provides 24-hour online support. Please contact them in advance if you encounter any problems.

For further assistance, please refer to the contact information provided in your product's quick start guide or visit the official dyplay webເວັບໄຊ.
