1. ບົດແນະນຳ
Thank you for choosing the Rocketfish RF-HTS4418 12-Outlet Power Center. This device is designed to protect your valuable electronics from power surges and spikes while providing ample power outlets and USB charging ports. Please read this manual thoroughly before using the product to ensure safe and optimal performance.
ຮູບພາບ 1.1: ດ້ານຫນ້າ view of the Rocketfish 12-Outlet Power Center.
2. ຂໍ້ມູນຄວາມປອດໄພ
ເພື່ອຫຼຸດຜ່ອນຄວາມສ່ຽງຂອງໄຟຟ້າຊັອດ, ໄຟໄຫມ້, ຫຼືການບາດເຈັບ, ປະຕິບັດຕາມຄວາມລະມັດລະວັງດ້ານຄວາມປອດໄພພື້ນຖານເຫຼົ່ານີ້ສະເຫມີ:
- Do not use this product near water or in excessively humid environments.
- Do not open the housing. There are no user-serviceable parts inside.
- Ensure the power center is plugged into a properly grounded outlet.
- Do not exceed the electrical ratings of the power center.
- Keep children away from the power center.
- Avoid running power cords under carpets or rugs.
3. ເນື້ອໃນຊຸດ
ກວດສອບວ່າລາຍການດັ່ງຕໍ່ໄປນີ້ແມ່ນລວມຢູ່ໃນຊຸດຂອງທ່ານ:
- Rocketfish RF-HTS4418 12-Outlet Power Center
- ຄູ່ມືຜູ້ໃຊ້ (ເອກະສານນີ້)
4. ຄຸນລັກສະນະຂອງຜະລິດຕະພັນ
The Rocketfish RF-HTS4418 Power Center offers advanced features for comprehensive protection and convenience:
- 12 ປ່ຽງ AC: ສະຫນອງ ampການເຊື່ອມຕໍ່ພະລັງງານສຳລັບອຸປະກອນຫຼາຍອັນ.
- ພອດສາກ USB: ສາກໄຟອຸປະກອນມືຖືໄດ້ຢ່າງສະດວກສະບາຍ.
- ການປ້ອງກັນໄຟຟ້າ: Protects connected equipment from power surges and spikes with a 5280-joule rating.
- EMI/RFI Noise Filter: Reduces electromagnetic and radio frequency interference for cleaner power delivery.
- Pro ຕໍ່າfile ການອອກແບບ: Allows for placement in limited spaces.
- ຄວາມເຂົ້າກັນໄດ້ທົ່ວໂລກ: Suitable for computers, TVs, and various household appliances.
Image 4.1: The power center features a 5280-joule rating for robust surge protection.
Image 4.2: Detail of the 12 AC outlets and multiple USB ports.
Image 4.3: Features such as the 47dB EMI/RFI Noise Filter and low profile ການອອກແບບ.
Image 4.4: Universal compatibility for various electronic devices.
5. ຕັ້ງຄ່າ
- ການຈັດວາງ: Position the power center in a dry, indoor location, away from heat sources and direct sunlight. Its low-profile design allows for flexible placement.
- ເຊື່ອມຕໍ່ຫາ Wall Outlet: Plug the power center's main power cord into a standard, grounded 240V AC wall outlet.
- ເຊື່ອມຕໍ່ອຸປະກອນ: Plug your electronic devices into the available AC outlets. For charging mobile devices, use the USB ports.
- Coaxial/Phone Line Protection (if applicable): If your model includes coaxial or phone line protection, connect your incoming line to the 'IN' port and your device to the 'OUT' port.
Image 5.1: The power center's main plug for connection to a wall outlet.
6. ຄໍາແນະນໍາການດໍາເນີນງານ
Once connected, the Rocketfish Power Center operates automatically to protect your devices.
- ຕົວຊີ້ບອກພະລັງງານ: A light on the power center indicates that it is receiving power and the surge protection is active.
- ການປ້ອງກັນການໂຫຼດເກີນ: In case of an overload, the circuit breaker may trip. If this happens, unplug some devices, then press the reset button (if available) to restore power.
- ການສາກ USB: Simply connect your USB-powered devices to the USB ports for charging. The power center will automatically detect and deliver the appropriate charging current.
ວິດີໂອ 6.1: ຫຼາຍກວ່າview of the Rocketfish Power Center's features and functionality.
Video 6.2: Demonstration of connecting devices to the power center.
7. ບໍາລຸງຮັກສາ
The Rocketfish Power Center requires minimal maintenance:
- ທໍາຄວາມສະອາດ: Unplug the power center from the wall outlet before cleaning. Use a soft, dry cloth to wipe the exterior. Do not use liquid cleaners or aerosols.
- ການກວດກາ: Periodically inspect the power cord and the unit for any signs of damage. If damage is present, discontinue use and contact support.
8. ການແກ້ໄຂບັນຫາ
| ບັນຫາ | ສາເຫດທີ່ເປັນໄປໄດ້ | ການແກ້ໄຂ |
|---|---|---|
| ບໍ່ມີໄຟໃຫ້ກັບອຸປະກອນທີ່ເຊື່ອມຕໍ່. | Power center not plugged in, wall outlet not working, circuit breaker tripped. | Ensure power center is securely plugged in. Test wall outlet with another device. Reset the power center's circuit breaker if tripped. |
| ພອດ USB ບໍ່ໄດ້ສາກໄຟ. | Device not compatible, cable faulty, power center not receiving power. | Check device compatibility. Try a different USB cable. Ensure the power center is powered on. |
| ໄຟຕົວຊີ້ວັດພະລັງງານຖືກປິດ. | No power to the unit, surge protection compromised. | Check wall outlet. If the indicator remains off after confirming power, the surge protection may have been sacrificed to protect your devices. The unit may still function as a power strip, but surge protection is no longer active. Replace the unit for continued surge protection. |
9. ຂໍ້ມູນຈໍາເພາະ
- ຕົວແບບ: RF-HTS4418
- ປລັກສຽບໄຟທັງໝົດ: 12
- ສະບັບtage: 240 ໂວນ
- ການປ້ອງກັນໄຟຟ້າ: 5280 ຈູນ
- ຄຸນນະສົມບັດພິເສດ: Surge Protection, USB Slots, EMI/RFI Noise Filter
- ຂະໜາດຜະລິດຕະພັນ: 17.33 x 10.56 x 3.85 ນິ້ວ (44.02 x 26.82 x 9.78 cm)
- ນ້ໍາຫນັກລາຍການ: 6.25 ປອນ (2.83 ກິໂລ)
- ການນໍາໃຊ້ທີ່ແນະນໍາ: Apartment, Home Theater, Office
- ທໍາອິດທີ່ມີຢູ່: ວັນທີ 13 ມິຖຸນາ 2018
10. ການຮັບປະກັນແລະການສະຫນັບສະຫນູນ
Rocketfish products are designed for reliability and performance. This product includes a lifetime equipment guarantee, protecting your connected devices up to $1,000,000 against surge damage when properly connected.
For technical support, warranty claims, or further assistance, please visit the official Rocketfish webຫຼື ຕິດຕໍ່ບໍລິການລູກຄ້າຂອງເຂົາເຈົ້າ. ເກັບໃບຮັບເງິນການຊື້ຂອງທ່ານໄວ້ເພື່ອຈຸດປະສົງການຮັບປະກັນ.
ສະຫນັບສະຫນູນອອນໄລນ໌: www.rocketfishproducts.com/support (ຕ. ຢample link, ກະລຸນາເບິ່ງເອກະສານຜະລິດຕະພັນຕົວຈິງເພື່ອໃຫ້ຖືກຕ້ອງ URL)
